HP C30 - Front Cover Removal

Front Cover Removal
June 1999 Removal/Replacement Procedures 7-5
Front Cover Removal
To remove the front cover:
1 Open the front cover.
2 While holding the cover up halfway, unhook the strap from the right side.
3 Duplex only: Remove the strap from the left side.
4 Slide the front cover to the right off its hinges.
Left Strap
Right Strap
