Photoconductor Seam Sensor Removal
7-34 Removal/Replacement Procedures June 1999
7 From inside the empty photoconductor cavity, disconnect connector CN63.
8 Lift the photoconductor seam sensor and bracket up out of the printer.
Note: Use caution not to bend the bracket.
Seam Sensor
and Bracket
CN63
Front Detail
