1400-Sheet Stacker
8-12 Options June 1999
Connector Locations
Figure 8-6. Connector Locations (front view, cover removed)
Connectors/circuit boards shown with broken lines are concealed from view.
Figure 8-7. Connector Locations (left side view, left cover removed)
CN416
Printer side
CN409
CN426
CN425
CN405
CN406
CN401
CN404
CN402
CN403
CN412
Fuse 1
Fuse 2
Power supply
CN417
Frame ground
Rear side
Output control
board
Front side
