HP C30 - Page 457

1400-Sheet Stacker
June 1999 Options 8-13
Figure 8-8. Rear Side View (cover removed)
Connectors/circuit boards shown with broken lines are concealed from view.
Figure 8-9. Top View (top cover removed)
CN415
Printer side
Output side
CN424 (AC power)
CN420 (Control connector plug)
CN413
CN419
CN414
CN408
CN407
Printer side
Output side
