1400-Sheet Stacker
8-14 Options June 1999
Output Control Board Logic
The table below details specific stacker actions and which sensors supply the signals
needed for each action. Signals from the printer are also included.
Table 8-4. Stacker Actions and Sensor Inputs
Action Sensor Input
Elevator up
(Wait signal to printer)
OULS
OLLS
OELS
Elevator stop OULS
OLLS
OELS
Remove prints
(signal to printer)
OULS
OLLS
OELS
Elevator down OULS
OLLS
OELS
Paper exit EPS
OEPS
Paper exit jam (023) OEPS
Jogging start From printer
Jogging ERS (from printer)
OJRS
OEPS
OJFS
Jogging stop From printer
