Display assembly subcomponents
Item Component Spare part number
(1) Display bezel L14912-001
(2) Webcam/microphone module (does not include cable; includes double-sided adhesive) L07235-001
(3) Display panel bracket L14913-001
(4) Display panel (does not include display panel cable):
For use only on computer models equipped with an HD BrightView TouchScreen
display assembly
L14918-001
For use only on computer models equipped with an AntiGlare TouchScreen display assembly L22362-001
For use only on computer models equipped with non-TouchScreen display assembly L14917-001
(5) Display panel cable:
For use only on computer models equipped with an HD BrightView TouchScreen
display assembly
L14916-001
For use only on computer models equipped with an AntiGlare TouchScreen display assembly L14915-001
12 Chapter 3 Illustrated parts catalog
