Display assembly subcomponents
Table 3-3 Display components and their descriptions
Item Component Spare part number
(1) Display bezel
Ash grey L91534-001
Mineral silver L91535-001
(2) Display panel (includes display tape and panel adhesive)
FHD, antiglare L91591-001
FHD, antiglare, Touch-on Panel (TOP) L91592-001
HD, antiglare L91593-001
HD, BrightView, Touch-on Panel (TOP) L91594-001
(3) Display hinges (left and right) (include display tape) L91537-001
(4) Display panel cable (includes display tape)
For use with touch displays L91539-001
For use with nontouch displays L91538-001
(5) Webcam/microphone module L91540-001
(6) Wireless antennas (dual) (includes display tape) L91533-001
(7) Webcam cable (includes display tape) L91541-001
Display assembly subcomponents 13
