Remove the display assembly:
1. Disconnect the display panel cable (1) from the system board.
2. Disconnect the WLAN antenna cables (2) from the terminals on the WLAN module.
NOTE: The WLAN antenna cable labeled “1” connects to the WLAN module “Main” terminal
labeled “1”. The WLAN antenna cable labeled “2” connects to the WLAN module “Aux” terminal
labeled “2”.
3. Release the WLAN antenna cables from the routing channel (3) built into the base enclosure.
4. Disconnect the WWAN antenna cables (4) from the terminals on the WWAN module.
NOTE: The WWAN antenna cable labeled “5” connects to the WWAN module “Main”
terminal labeled “5”. The WWAN antenna cable labeled “6” connects to the WWAN module
“Aux/GPS” terminal labeled “6”.
5. Release the WWAN antenna cables from the routing channel (5) built into the base enclosure.
6. Remove the two Phillips PM2.5×5.5 screws (1) that secure the display assembly to the
base enclosure.
Component replacement procedures
41

HP Chromebook14 Specifications

General

Display Size	14 inches
Operating System	Chrome OS
Wireless	802.11a/b/g/n/ac
RAM	2GB
Storage	16GB eMMC
Display Resolution	1366 x 768
Bluetooth	Bluetooth 4.0
Ports	2 x USB 3.0, 1 x HDMI, 1 x Headphone/Microphone combo jack
Graphics	Intel HD Graphics
