e. Remove the display panel (3).
The display panel is available using spare part number 740155-001.
10. If it is necessary to replace the webcamera/microphone module:
CAUTION: Handle the webcamera/microphone module with caution. This module has a thin
profile and is susceptible to damage when not handled carefully.
a. Detach the webcamera/microphone module (1) from the display enclosure by carefully lifting
up on the left side of the module. (The webcamera/microphone module is attached to the
display enclosure with double-sided adhesive.)
b. Disconnect the webcamera/microphone module cable (2) from the webcamera/
microphone module.
Component replacement procedures
45
