C7085-90921 Chapter 8 Parts and diagrams 335
CAUTION Two versions of the HP Color LaserJet 4500 series printers are available. Before ordering parts, you
will need to identify which printer version you are servicing. For more information, see page 329. The
4550 series has some different service parts from the 4500 series.
Note Early CLJ4500 printers (serial numbers xxGxxxxxxx and below) have two versions of the drum drawer
cover and the upper (drum) drawer assembly (Figure 8-7, item 6 and Figure 8-13, item 1). If the drum
drawer cover requires replacement, first determine whether you have the original version of the drum
drawer by locating a bar code label with a part number of RG5-3315 on the inside of the drum drawer
cover, just to the right of the fan cover. If you have the original version of the drum drawer, order kit
part number RG5-5230-000CN to obtain the newer version of the drum drawer assembly, drum drawer
cover, plus additional hardware required to complete the update. If the newer version of the drum
drawer is already installed, simply order the replacement drum drawer cover (RG5-5232-000CN).
Table 8-4 Printer cover and door
Ref. Description Qty. Parts for 4500
series s/n xxG...
and below
Parts for 4500
series s/n xxH...
and above
Parts for 4550
series
1 Cover, right side 1 RB2-1203-000CN RB2-1203-000CN RB2-1203-000CN
2 Cover, connector 1 RB2-1224-000CN RB2-1224-000CN RB2-1224-000CN
3 Cover, right front 1 RG5-3310-000CN RG5-3310-000CN RG5-3310-000CN
4 Cable, control panel 1 RG5-3802-000CN RG5-5195-000CN RG5-5195-000CN
5 Control panel assembly 1 RG5-5200-000CN RG5-5200-000CN RG5-5200-000CN
6 Cover, ITB drawer 1 RG5-3320-000CN RG5-3320-000CN RG5-3320-000CN
7 Tray, extension 1 RB2-1215-000CN RB2-1215-000CN RB2-1215-000CN
8 Cover, drum drawer 1 RG5-5232-000CN** RG5-5152-000CN RG5-5152-000CN
9 Cover, left side 1 RG5-3313-000CN RG5-5151-000CN RG5-5151-000CN
10 Cover, lower rear 1 RB2-1206-000CN RB2-1206-000CN RB2-1206-000CN
11 Door, rear access 1 RG5-3325-040CN RG5-3325-040CN RG5-3325-040CN
12 Cover, rear 1 RB2-1205-000CN RB2-1205-000CN RB2-1205-000CN
**Refer to note, below.
