HP color laserJet 4550 series - Page 338

336 Parts and diagrams C7085-90921
Figure 8-5 Top cover assembly
CAUTION Two versions of the HP Color LaserJet 4500 series printers are available. Before ordering parts, you
will need to identify which printer version you are servicing. For more information, see page 329. The
4550 series has some different service parts from the 4500 series.
Table 8-5 Top cover components
Ref. Description Qty. Parts for 4500
series s/n xxG...
and below
Parts for 4500
series s/n xxH...
and above
Parts for 4550
series
1 Cover, top 1 RG5-3300-000CN RG5-5150-000CN RG5-5150-000CN
2 Cover, toner access 1 RF5-2076-000CN RF5-3137-000CN RF5-3137-000CN
1
2
