92 Printer maintenance C7085-90921
Replacing the fuser kit
Replace the fuser kit when the printer control panel displays:
FUSER LIFE OUT REPLACE KIT.
The fuser kit contains one fuser, four paper rollers, and a hand wipe.
WARNING!
To prevent possible burns, be sure the power cord is unplugged and
that the printer has cooled for 30 minutes.
1 Open the upper-rear door of the duplex unit, if attached.
2 Open the upper-rear door of the printer.
3 Release the straps from the rear door by squeezing the latches on
the straps where the latches connect to the rear door.
4 Inside the back of the printer, near the bottom, locate the two blue
latches on the fuser.
1
2
4
3
