Left cover
1. Remove one screw (callout 1).
Figure 6-40 Remove the left cover (1 of 4)
1
2. Open the front door, and then use a small flatblade screwdriver to release four tabs (callout 2).
Figure 6-41 Remove the left cover (2 of 4)
2
ENWW External panels, covers, and doors 135
