Diagrams
Block diagrams
Scanner and automatic document feeder (ADF) assemblies
Figure 7-1 Scanner assembly (base models)
Table 7-1 Scanner assembly (base models)
Item Description
1 Scanner
2 Control panel
Figure 7-2 Scanner and ADF assemblies (fax/memory-card models)
Table 7-2 Scanner and ADF assemblies (fax/memory-card models)
Item Description
1 Control panel
2 ADF
