Table 8-9 External panels and covers
Ref Description Part number Qty
2 Rear upper cover RC2-3942-000CN 1
3 Rear center cover RC2-3959-000CN 1
4 Rear door RC2-3956-000CN 1
5 Rear lower cover RC2-3958-000CN 1
7 Upper cover assembly RM1-4921-000CN 1
8 Right cover RC2-3943-000CN 1
9 Front right cover RC2-3945-000CN 1
10 Left cover RC2-3944-000CN 1
12 Front door RC2-3955-000CN 1
13 Front lower cover RL1-1832-000CN 1
14 Blanking cover RC2-3957-000CN 1
15 Card cover RC2-3951-000CN 1
Memory card bezel (not shown) CC431-40057 1
16 Light guide RC2-3098-000CN 1
17 Speaker Q3948-60113 1
ENWW Covers 271
