Alphabetical parts list
Table 8-14 Alphabetical parts list
Description Part number Table and page
Button, power RC2-3612-000CN Covers, panels, and doors
on page 235
Cable, flat RK2-2302-000CN Internal components (4 of 7)
on page 243
Cap, link RC2-3599-000CN Internal components, simplex
products (6 of 7) on page 247
Cap, link RC2-3774-000CN Internal components, duplex
products (7 of 7) on page 249
Cartridge-tray assembly RM1-4836-000CN Internal components (1 of 7)
on page 237
Cassette (Tray 2) RM1-4860-000CN Cassette (Tray 2) on page 251
Color misregistration sensor assembly RM1-4850-000CN Internal components (2 of 7)
on page 239
Control-panel assembly RM1-4832-000CN Covers, panels, and doors
on page 235
Cover, DIMM RC2-3614-000CN Covers, panels, and doors
on page 235
Cover, holder RC2-2014-000CN Internal components (3 of 7)
on page 241
Cover, left RC2-3606-000CN Covers, panels, and doors
on page 235
Cover, lower-rear RC2-3748-000CN Internal components, duplex
products (7 of 7) on page 249
Cover, rear RC2-3605-000CN Internal components, simplex
products (6 of 7) on page 247
Cover, right RC2-3618-000CN Covers, panels, and doors
on page 235
Cover, right-front RC2-3611-000CN Covers, panels, and doors
on page 235
Cover, upper assembly RM1-4831-000CN Covers, panels, and doors
on page 235
Cover, upper-rear RC2-3791-000CN Internal components, duplex
products (7 of 7) on page 249
DC controller PCA RM1-5431-000CN PCAs on page 255
Door, front assembly RM1-4848-000CN Covers, panels, and doors
on page 235
Door, rear RC2-3604-000CN Internal components, simplex
products (6 of 7) on page 247
Door, rear assembly RM1-4878-000CN Internal components, duplex
products (7 of 7) on page 249
Driver PCA RM1-5288-000CN PCAs on page 255
258 Chapter 8 Parts and diagrams ENWW
