6. To remove the display/webcam cable, remove the cable from the clips built into the display enclosure
(1), and then remove the cable from the display enclosure (2).
NOTE: If replacing the display enclosure, be sure that the subcomponents (including the webcam/
microphone module, the antenna receivers, and all associated cables and hardware) are transferred to
the new enclosure.
Reverse this procedure to reassemble and install the display assembly.
82 Chapter 4 Removal and replacement procedures
