HP Compaq 2710p Maintenance And Service Guide

Display assembly
NOTE: All display assembly spare part kits include an ambient light sensor, fingerprint reader,
microphones, WLAN antenna cables, and WWAN antenna cables
Description Spare part number
Display assembly with camera and keyboard light 454679-001
Display assembly with camera 454675-001
Display assembly with keyboard light 454677-001
Display assembly 454676-001
Before removing the display assembly, follow these steps:
1.
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4.
Remove the battery (see
Battery on page 37).
5.
Disconnect the wireless antenna cables from the WLAN module (see
WLAN module on page 41)
and the WWAN module (see
WWAN module on page 45).
6.
Remove the following components:
a.
Hard drive compartment cover (see
Hard drive on page 39)
b.
Keyboard (see
Keyboard on page 48)
c.
Hinge cover (see
Hinge cover on page 50)
d.
Top cover (see
Top cover on page 52)
Remove the display assembly:
1.
Place the display into an upright position.
2.
Disconnect the following cables from the system board:
(1) Fingerprint reader board cable
(2) Camera cable
(3) Keyboard light cable
60 Chapter 4 Removal and replacement procedures

HP Compaq 2710p Specifications

General

Tjunction	100 °C
FSB Parity	No
Processor cache	2 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor socket	LGA 3647 (Socket P)
Processor codename	Merom
Processing Die size	143 mm²
Processor frequency	1.33 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	533 MHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	10 W
Number of Processing Die Transistors	291 M
HDD speed	4200 RPM
Optical drive type	DVD Super Multi
Total storage capacity	120 GB
Display diagonal	12.1 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Internal memory	2 GB
Memory clock speed	667 MHz
Internal memory type	DDR2-SDRAM
Discrete graphics card	Yes
Discrete graphics card model	Intel® GMA X3100
Maximum graphics card memory	0.384 GB
Type	PC
Modem speed	56 Kbit/s
Dimensions (WxDxH)	290 x 212 x 28.2 mm
Wireless technology	802.11a/b/g/draft-n, a/b/g, b/g
Bluetooth version	2.0+EDR
Operating system installed	Windows Vista Business
Number of battery cells	6
Serial ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Processor ARK ID	33920
Processor package size	35 x 35 mm
Country of origin	China

Weight and Dimensions

Depth	290 mm
Width	212 mm
Height	28.2 mm
Weight	1650 g
