12. Rotate the slot cover retention latch back in place to secure the expansion card.
Figure 2-15 Closing the Expansion Slot Retainer
13. Connect external cables to the installed card, if needed. Connect internal cables to the system
board, if needed.
14. Replace the access panel.
15. Reconnect the power cord and turn on the computer.
16. Lock any security devices that were disengaged when the access panel was removed.
17. Reconfigure the computer, if necessary. Refer to the Computer Setup (F10) Utility Guide for
instructions on using Computer Setup.
Drive Positions
Figure 2-16 Drive Positions
ENWW Drive Positions 21
