HP COMPAQ 6005 User Manual

HP DisplayPort to VGA
Adapter
Connectors DisplayPort and VGA connector
Adapter length 8 in (20 cm)
Adapter weight .1 lbs (.06 kg)
Maximum vertical refresh
rate
85 Hz
Display support 162 MHz RAMDAC
Display max resolution 1600x1200
HP DisplayPort to VGA adapter display resolutions and refresh rates
NOTE: Other resolutions may be available but are not recommended as they may not have been tested and qualified by HP.
Using the HP DisplayPort to VGA Adapter may require an update to the graphics driver installed on your system. To install
the most up-to-date graphics driver go to: www.hp.com .
Resolution Max refresh rate
640x480 85
800x600 85
1024x768 85
1280x720 85
1280x1024 85
1440x900 75
1600x1200 60
1680x1050 60
1920x1080 60-R
1920x1200 60-R
NOTE: 60-R denotes reduced blanking timings are used. Not all monitors support reduced blanking timing.
QuickSpecs
HP Compaq 6005 Pro Business PC
Technical Specifications - Graphics
DA - 13412 Worldwide QuickSpecs — Version 6 — 10/14/2009 Page 27

HP COMPAQ 6005 Specifications

General

Chipset	AMD 785G
Memory	Up to 16 GB DDR3 SDRAM
Graphics	Integrated ATI Radeon HD 4200
Network	Integrated Gigabit Ethernet
Processor	AMD Athlon II or AMD Phenom II
Storage	Up to 1 TB HDD
Optical Drive	DVD-ROM
Operating System	Windows 7 Professional
Audio	Integrated High Definition Audio
Expansion Slots	1 PCIe x16, 2 PCIe x1, 1 PCI
Ports	USB 2.0, VGA, DisplayPort, serial, parallel
Power Supply	240W or 320W
Form Factor	Small Form Factor (SFF)
