HP COMPAQ 6005 User Manual

64 GB Solid State Drive Capacity 64 GB
NAND Flash Memory Multi Level Cell (MLC) with wear leveling controller
Interface type SATA 3Gb/sec
Dimensions-external
(W x H x D)
2.74 x 0.37 x 4 in (6.98 x 0.95 x 10.2 cm)
Weight 0.14 lb (65 g)
Internal transfer rate Write speed Up to 220 MB/s
Read speed Up to 120 MB/s
Host transfer rate Ultra DMA mode Up to 150 MB/s
Power DC power requirement 5 VDC 5%-100 mV ripple p-p
Total power
consumption
<1.12Watt
Environmental
(all conditions, non-
condensing)
Temperature (operating) 32° to 158° F (0° to 70° C)
Relative Humidity
(operating)
5% to 95%
Maximum Wet Bulb
Temperature (operating)
84° F (29° C)
Regulations UL, CSA, EN 60950-2000, CISPR Pub 22 Class B, CNS 13438,
AS/NZS CISPR 22:2002 Class B, R1113 and C1172 Class B
* For solid state disk drives, GB means 1 billion bytes. 16GB is the unformatted capacity of this
drive before a portion of the drive is reserved for flash management features. Actual capacity
varies by content and will be less than 15.8GB.
QuickSpecs
HP Compaq 6005 Pro Business PC
Technical Specifications - Internal Storage
DA - 13412 Worldwide QuickSpecs — Version 6 — 10/14/2009 Page 30

HP COMPAQ 6005 Specifications

General

Chipset	AMD 785G
Memory	Up to 16 GB DDR3 SDRAM
Graphics	Integrated ATI Radeon HD 4200
Network	Integrated Gigabit Ethernet
Processor	AMD Athlon II or AMD Phenom II
Storage	Up to 1 TB HDD
Optical Drive	DVD-ROM
Operating System	Windows 7 Professional
Audio	Integrated High Definition Audio
Expansion Slots	1 PCIe x16, 2 PCIe x1, 1 PCI
Ports	USB 2.0, VGA, DisplayPort, serial, parallel
Power Supply	240W or 320W
Form Factor	Small Form Factor (SFF)
