Interface modes
USB communications through USB port
SCM protocol
Automatic card insertion/removal detection
Reader performance
interface
USB connection
Electro-magnetic
standards
Europe
89/336/CEE guideline
USA
USAFCC part 15
HP USB 2-Button Laser
Mouse
Scroll Wheel
24
Maximum Rotation
Speed
48 rats/sec
Switch Type
wheel
Switch Life
Button - 3,000,000
Wheel - 1,000,000 times
Tilt switch - 500,000 times
Environmental
Operating Temperature
32° to 104° F (0° to 40° C)
Non-operating
Temperature
-4° to 140° F (-20° to 60° C)
Operating Humidity
10% to 90% (non-condensing at ambient)
Non-operating
Humidity
20% to 80% (non-condensing at ambient)
Operating Shock
40 g, six surfaces
Non-operating Shock
80 g, six surfaces
Operating Vibration
2-g peak acceleration
Non-operating
Vibration
4-g peak acceleration
Electrical
Operating Voltage
+ 5VDC ± 5%
Power Consumption
MTBF
> 150,000 hrs
ESD
IEC-61000-4-2 criteria B, Contact discharge:
+/- 4kV, Air discharge: +/- 8kV
EMI-RFI
FCC Class B
PC98
PC 99 Compliant
Mechanical
Resolution
800dpi
Tracking Speed
25 cm/sec
Acceleration
0.5mm
Switch Actuation
0.6N (60gf)
Switch Life
Button - 3,000,000
Wheel - 1,000,000 times
Tilt switch - 500,000 times
Cable Length
1850mm
PC98-99
PC99 compliant
Regulatory Approvals
UL60950-1, UL 94, UL 746 (A-E), UL 796
TUV/GS: EN 60950-1, EN 60825-1
FCC Class B, UL 1950, cUL, TUV GS, CE, C-tick, VCCI, BSMI, RRL
QuickSpecs
HP Compaq 6005 Pro Business PC
Technical Specifications - Input/Output Devices
DA - 13412 Worldwide QuickSpecs — Version 6 — 10/14/2009
Page 34

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP COMPAQ 6005 and is the answer not in the manual?

HP COMPAQ 6005 Specifications

General IconGeneral
ChipsetAMD 785G
MemoryUp to 16 GB DDR3 SDRAM
GraphicsIntegrated ATI Radeon HD 4200
NetworkIntegrated Gigabit Ethernet
ProcessorAMD Athlon II or AMD Phenom II
StorageUp to 1 TB HDD
Optical DriveDVD-ROM
Operating SystemWindows 7 Professional
AudioIntegrated High Definition Audio
Expansion Slots1 PCIe x16, 2 PCIe x1, 1 PCI
PortsUSB 2.0, VGA, DisplayPort, serial, parallel
Power Supply240W or 320W
Form FactorSmall Form Factor (SFF)
