HP COMPAQ 6005

Microtower and Small Form Factor
Maximum Memory * Supports up to 16GB of un-buffered non-ECC DDR3 SDRAM.
The DIMM connectors for Channel A slot 3 and Channel B slot 4 are black and these slots
must always be populated first in the channel. Not all possible memory configurations are
represented in the table below.
NOTE: For systems configured with more than 3GB of memory and a 32-bit operating
system, all memory may not be available to the OS due to system resource requirements.
Addressing memory above 4GB requires a 64-bit operating system.
Total Memory DIMM Slot Population
Channel A Channel B
1 (white) 3 (black) 2 (white) 4 (black)
1-GB
(Single Channel)
1GB
2-GB
(Dual Channel)
1GB 1GB
3-GB
(Dual Channel)
2GB 1GB
4-GB
(Dual Channel)
2GB 2GB
4-GB
(Dual Channel)
1GB 1GB 1GB 1GB
8-GB
(Dual Channel)
2GB 2GB 2GB 2GB
16-GB maximum
(Dual Channel)
4GB 4GB 4GB 4GB
Expandability Microtower Small Form Factor
PCI slots 1 full-height 1 low-profile
Max power per slot 35W 35W
PCIe x1 slot 2 2
Max power per slot 10W 10W
PCIe x16 slot 1 full-height 1 low-profile
Max power per slot 75W 35W
External Bays
3.5" 1 1
5.25" 2 1
IDE
Internal 3.5" HDD Bays 2 1
Hard Drive Controller
(SATA) Supported
SATA SATA
Hard Drive Interfaces
Supported
SATA 3.0Gb/s SATA 3.0Gb/s
QuickSpecs
HP Compaq 6005 Pro Business PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13412 Worldwide QuickSpecs — Version 6 — 10/14/2009 Page 9
