HP Compaq 6530b User Manual

Select To do this
●
Enable/disable CD-ROM boot (enabled by default).
●
Enable/disable SD Card boot (enabled by default).
●
Enable/disable diskette boot (enabled by default).
●
Enable/disable boot from Extensible Firmware Interface (EFI) File (select models only;
enabled by default).
●
Enable/disable internal network adapter boot and set the Preboot eXecution
Environment (PXE) (enabled by default).
●
Set the Express Boot Popup delay in seconds.
●
Set the boot order.
Device Configurations
●
Enable/Disable Unified Extensible Firmware Interface (UEFI) mode (disabled by
default).
●
Enable/disable USB legacy support (enabled by default). When enabled, USB legacy
support allows the following:
◦
Use of a USB keyboard in Computer Setup even when a Windows® operating
system is not running.
◦
Startup from bootable USB devices, including a hard drive, diskette drive, or
optical drive connected by a USB port to the computer.
●
Select a parallel port mode: ECP (Enhanced Capabilities Port), standard, bidirectional,
or EPP (Enhanced Parallel Port).
●
Enable/disable BIOS DMA data transfers (select models only; enabled by default).
●
Enable/disable fan always on while connected to an AC outlet (disabled by default).
●
Enable/disable LAN Power Save. When enabled, saves power by turning off the LAN
when not in use (enabled by default).
●
Enable/disable Data Execution Prevention. When enabled, the processor can disable
some virus code execution, which helps to improve computer security.
●
SATA (Serial Advanced Technology Attachment) device mode. The following options
are available:
◦
AHCI (Advanced Host Controller Interface)
◦
IDE (Integrated Drive Electronics)
NOTE: Availability of the options above varies by computer model.
●
Enable/disable secondary battery fast charge (enabled by default).
●
Enable/disable HP QuickLook 2 (enabled by default).
●
Enable/disable Virtualization Technology (select models only; enabled by default).
●
Enable/disable TXT (Intel® Trusted Execution Technology) (select models only;
enabled by default).
●
Enable/disable Dual Core CPU (select models only; enabled by default).
Built-In Device Options
●
Enable/disable the wireless button state (enabled by default).
●
Enable/disable embedded WWAN device radio (select models only; enabled by
default).
Computer Setup Menus 107

HP Compaq 6530b Specifications

General

HDD speed	7200 RPM
HDD interface	-
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	160 GB
Number of HDDs installed	1
Bus type	FSB
Stepping	R0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo P8000 Series
Processor socket	Socket 479
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.53 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Motherboard southbridge	Intel ICH9M
Processor front side bus	1066 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	25 W
Processor core voltage (AC)	1.00 - 1.250 V
CPU multiplier (bus/core ratio)	9.5
Number of Processing Die Transistors	410 M
Operating system installed	Windows Vista Business
Operating system architecture	32-bit
Display diagonal	14.1 \
Display resolution	- pixels
Motherboard chipset	Intel GE45 Express
Memory slots	2x SO-DIMM
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 2 GB
Type	PC
Power supply type	AC/DC
Wireless technology	Wi-Fi
Compatible operating systems	Windows Vista
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Audio system	HD
Pointing device	Touchpad + Scroll zone
Bluetooth version	2.0+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
TV-out type	S-Video
Charging port type	DC-in jack
USB 2.0 ports quantity	4
CardBus PCMCIA slots quantity	0
Cable lock slot type	Kensington
AC adapter power	55 W
Number of battery cells	6
Product color	Black
Country of origin	China
Discrete graphics card model	Intel® GMA 4500MHD
Processor code	SLGFE
Processor ARK ID	37006
Processor package size	35 x 35 mm

Weight and Dimensions

Depth	242.8 mm
Width	334.8 mm
Weight	2410 g
Height (front)	32.6 mm
