Phillips PM2.5×10.0 captive screw
Color Quantity Length Thread Head diameter
Silver 16 10.0 mm 2.5 mm 5.0 mm
Where used: 4 captive screws that secure the discrete heat sink to the PM45 system board for use only
with HP Compaq 6730s Notebook PC models (screws are secured to the heat sink by C-clips)
138 Chapter 7 Screw listing
