Spare part
number
Description
490371-AR1 Power cord for use in South Africa
490371-BB1 Power cord for use in Israel
490371-D01 Power cord for use in Argentina
490371-D61 Power cord for use in India
491250-001 System Board (includes replacement thermal material and the ExpressCard assembly) for use only with
computer models equipped with Intel processors with UMA graphics subsystem memory
491251-001 Webcam module for use only with HP Compaq 6730s Notebook PC models
491252-001 Base enclosure (includes rubber feet) for use only with HP Compaq 6730s Notebook PC models
491253-001 Plastics Kit for use only with HP Compaq 6730s Notebook PC models (see Plastics Kit on page 28 for more
Plastics Kit spare part information)
491254-001 Top cover (includes TouchPad board and cable, and TouchPad button board and cable)
491255-001 Heat sink for use only with HP Compaq 6730s Notebook PC models
491256-001 Display inverter for use only with HP Compaq 6730s Notebook PC models
491257-001 Display bezel and cover for use only with HP Compaq 6730s Notebook PC models not equipped with a
webcam
491258-001 Display bezel and cover with webcam for use only with HP Compaq 6730s Notebook PC models equipped
with a webcam
491259-001 Display Cable Kit for use only with HP Compaq 6730s Notebook PC models
491260-001 LCD miscellaneous for use only with HP Compaq 6730s Notebook PC models
491261-001 15.4-inch WXGA display assembly for use only with HP Compaq 6730s Notebook PC models
491262-001 15.4-inch WXGA BrightView display assembly for use only with HP Compaq 6730s Notebook PC models
491263-001 15.4-inch WXGA display assembly with webcam for use only with HP Compaq 6730s Notebook PC models
491264-001 15.4-inch WXGA BrightView display assembly with webcam for use only with HP Compaq 6730s Notebook
PC models
491265-001 120-GB, 5400-rpm hard drive for use only with HP Compaq 6730s Notebook PC models (includes hard drive
bracket)
491266-001 120-GB, 7200-rpm hard drive for use only with HP Compaq 6730s Notebook PC models (includes hard drive
bracket)
491267-001 160-GB, 5400-rpm hard drive for use only with HP Compaq 6730s Notebook PC models (includes hard drive
bracket)
491268-001 250-GB, 5400-rpm hard drive for use only with HP Compaq 6730s Notebook PC models (includes hard drive
bracket)
491269-001 Optical drive connector
491270-001 DVD-ROM Drive for use only with HP Compaq 6730s Notebook PC models
491271-001 DVD/CD-RW Combo Drive for use only with HP Compaq 6730s Notebook PC models
491272-001 DVD±RW Double-Layer Drive with LightScribe for use only with HP Compaq 6730s Notebook PC models
491273-001 Blu-ray Disc ROM Drive with SuperMulti DVD±R/RW Double-Layer for use only with HP Compaq 6730s
Notebook PC models
36 Chapter 3 Illustrated parts catalog

HP Compaq 6730s Specifications

General

Bus type	FSB
Stepping	M0
Tjunction	100 °C
Processor cache	1 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel Pentium Mobile
Processor series	Intel Pentium T3000 Series for Mobile
Processor socket	Socket 478
Processor codename	Merom
Processing Die size	143 mm²
Processor frequency	2.16 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	667 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	13
Number of Processing Die Transistors	291 M
Motherboard chipset	Intel® PM45 Express
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	250 GB
Display surface	Matt
Display diagonal	15.4 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Type	PC
Modem speed	56 Kbit/s
Wireless technology	802.11a/b/g/n
Memory slots	2x SO-DIMM
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Audio system	HD Audio
Bluetooth version	2.0+EDR
Networking features	Fast Ethernet, WLAN
Operating system installed	FreeDOS
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	4
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Non-operating relative humidity (non-condensing)	5 - 95 %
AC adapter power	65 W
Pointing device	Touchpad + Scroll zone
Discrete graphics card model	Intel® GMA X4500HD
Processor code	SLB3P
Processor ARK ID	35583
Country of origin	China

Weight and Dimensions

Depth	266 mm
Width	358 mm
Weight	2500 g
Height (front)	32 mm
