Spare part
number
Description
491603-231 Keyboard for use in Slovakia only with HP Compaq 6735s Notebook PC models
491603-251 Keyboard for use in Russiaonly with HP Compaq 6735s Notebook PC models
491603-281 Keyboard for use in Thailand only with HP Compaq 6735s Notebook PC models
491603-291 Keyboard for use in Japan only with HP Compaq 6735s Notebook PC models
491603-A41 Keyboard for use in Belgium only with HP Compaq 6735s Notebook PC models
491603-AB1 Keyboard for use in Taiwan only with HP Compaq 6735s Notebook PC models
491603-AD1 Keyboard for use in South Korea only with HP Compaq 6735s Notebook PC models
491603-B31 Keyboard for International use only with HP Compaq 6735s Notebook PC models
491603-B71 Keyboard for use in Finland only with HP Compaq 6735s Notebook PC models
491603-BA1 Keyboard for use in Slovakia only with HP Compaq 6735s Notebook PC models
491603-BB1 Keyboard for use in Israel only with HP Compaq 6735s Notebook PC models
491603-BG1 Keyboard for use in Switzerland only with HP Compaq 6735s Notebook PC models
491603-DD1 Keyboard for use in Iceland only with HP Compaq 6735s Notebook PC models
491604-001 Base enclosure (includes rubber feet) for use only with HP Compaq 6735s Notebook PC models
481608-001 Cable Kit for use only with HP Compaq 6735s Notebook PC models (includes RJ-11 jack cable and USB
cable)
491610-001 Display Hinge Kit for use only with HP Compaq 6735s Notebook PC models (includes left and right hinges)
491612-001 Speakers for use only with HP Compaq 6735s Notebook PC models
491613-001 Thermal module for use only with HP Compaq 6735s Notebook PC models
491616-001 Plastics Kit for use only with HP Compaq 6735s Notebook PC models
491617-001 Screw Kit for use only with HP Compaq 6735s Notebook PC models
491620-001 Rubber Kit for use only with HP Compaq 6735s Notebook PC models
491621-001 Fan for use only with HP Compaq 6735s Notebook PC models
491622-001 Logo Kit for use only with HP Compaq 6735s Notebook PC models
491976-001 System board (includes replacement thermal material and the ExpressCard assembly) for use only with HP
Compaq 6730s Notebook PC models equipped with Intel processors with discrete graphics subsystem
memory (includes 256-MB of graphics subsystem memory)
491979-001 Thermal module for use only with HP Compaq 6730s Notebook PC models equipped with discrete graphics
subsystem memory
494106-01 System board (includes replacement thermal material and the ExpressCard assembly) for use only with HP
Compaq 6735s Notebook PC models equipped with UMA graphics subsystem memory
494108-001 Display bezel and cover for use only with HP Compaq 6735s Notebook PC models not equipped with a
webcam
494109-001 Display bezel and cover for use only with HP Compaq 6735s Notebook PC models equipped with a
webcam
494110-001 Webcam with module board for use only with HP Compaq 6735s Notebook PC models
494114-001 Display Cable Kit for use only with HP Compaq 6735s Notebook PC models
40 Chapter 3 Illustrated parts catalog

HP Compaq 6730s Specifications

General

Bus type	FSB
Stepping	M0
Tjunction	100 °C
Processor cache	1 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel Pentium Mobile
Processor series	Intel Pentium T3000 Series for Mobile
Processor socket	Socket 478
Processor codename	Merom
Processing Die size	143 mm²
Processor frequency	2.16 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	667 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	13
Number of Processing Die Transistors	291 M
Motherboard chipset	Intel® PM45 Express
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	250 GB
Display surface	Matt
Display diagonal	15.4 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Type	PC
Modem speed	56 Kbit/s
Wireless technology	802.11a/b/g/n
Memory slots	2x SO-DIMM
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Audio system	HD Audio
Bluetooth version	2.0+EDR
Networking features	Fast Ethernet, WLAN
Operating system installed	FreeDOS
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	4
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Non-operating relative humidity (non-condensing)	5 - 95 %
AC adapter power	65 W
Pointing device	Touchpad + Scroll zone
Discrete graphics card model	Intel® GMA X4500HD
Processor code	SLB3P
Processor ARK ID	35583
Country of origin	China

Weight and Dimensions

Depth	266 mm
Width	358 mm
Weight	2500 g
Height (front)	32 mm
