Optional HP Ultra-
Optional HP Ultra-Optional HP Ultra-
Optional HP Ultra-
Capacity Battery
Capacity BatteryCapacity Battery
Capacity Battery
Dimensions
DimensionsDimensions
Dimensions
(H x W x L)
1.3 x 6.0 x 10.6 in (3.33 x 15.25 x 26.88 cm)
Weight
WeightWeight
Weight
1.77 lb (0.803 kg)
Cells/Type
Cells/TypeCells/Type
Cells/Type
12-cell Lithium-Ion
Energy
EnergyEnergy
Energy
Watt-hour Capacity
95Wh
Temperature
TemperatureTemperature
Temperature
Operating (Charging)
32° to 113° F (0° to 45° C)
Operating (Discharging)
14° to 140° F (–10° to 60° C)
Non-operating
–4° to 140° F (–20° to 60° C)
Battery Re-Charge Time
Battery Re-Charge TimeBattery Re-Charge Time
Battery Re-Charge Time
Smart Adapter
3 to 4 hours
System ON
4 to 5 hours (depending on system power
consumption)
Fuel Gauge
Fuel GaugeFuel Gauge
Fuel Gauge
When pressed, LEDs light indicating level of charge remaining on battery
Optional HP Extended Life
Optional HP Extended LifeOptional HP Extended Life
Optional HP Extended Life
Battery
BatteryBattery
Battery
Dimensions
DimensionsDimensions
Dimensions
(H x W x L)
1.0 x 3.9 x 8.7 in (2.5 x 10.0 x 22.0 cm)
Weight
WeightWeight
Weight
1.00 lb (0.455 kg)
Cells/Type
Cells/TypeCells/Type
Cells/Type
8-cell Lithium-Ion
Energy
EnergyEnergy
Energy
Watt-hour Capacity
52Wh
Temperature
TemperatureTemperature
Temperature
Operating (Charging)
32° to 113° F (0° to 45° C)
Operating (Discharging)
14° to 140° F (–10° to 60° C)
Non-operating
–4° to 140° F (–20° to 60° C)
Battery Re-Charge Time
Battery Re-Charge TimeBattery Re-Charge Time
Battery Re-Charge Time
System in OFF mode or
Standby
3 hours
System ON
3 to 5 hours (depending on system power
consumption)
HP Fast Charge
Charges the battery up to 90% within 90 minutes
when system is OFF
Fuel Gauge
Fuel GaugeFuel Gauge
Fuel Gauge
When pressed, LEDs light indicating level of charge remaining on battery
6-Cell (55WHr) Lithium-
6-Cell (55WHr) Lithium-6-Cell (55WHr) Lithium-
6-Cell (55WHr) Lithium-
Ion battery
Ion batteryIon battery
Ion battery
Dimensions
DimensionsDimensions
Dimensions
(H x W x L)
0.8 x 2.1 x 8.0 in (2.0 x 5.3 x 20.3 cm)
Weight
WeightWeight
Weight
0.737 lb (0.335 kg)
Cells/Type
Cells/TypeCells/Type
Cells/Type
6-cell Lithium-Ion
Energy
EnergyEnergy
Energy
Watt-hour Capacity
55Wh
Temperature
TemperatureTemperature
Temperature
Operating (Charging)
32° to 113° F (0° to 45° C)
Operating (Discharging)
14° to 140° F (–10° to 60° C)
Non-operating
–4° to 140° F (–20° to 60° C)
Battery Re-Charge Time
Battery Re-Charge TimeBattery Re-Charge Time
Battery Re-Charge Time
System in OFF Mode or
Standby
2.5 hours
System ON
3 to 5 hours (depending on system power
consumption)
HP Fast Charge
Charges the battery up to 90% within 90 minutes
when system is OFF
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007
Page 20

Other manuals for HP Compaq 6910p

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Compaq 6910p and is the answer not in the manual?

HP Compaq 6910p Specifications

General IconGeneral
Bus typeFSB
SteppingM0
Tjunction105 °C
Processor cache3 MB
Processor cores2
Processor modelT8300
System bus rate- GT/s
Processor familyIntel® Core™2 Duo
Processor seriesIntel Core 2 Duo T8000 Series
Processor socketSocket 479
Processor codenamePenryn
Processing Die size107 mm²
Processor frequency2.4 GHz
Processor cache typeL2
Processor lithography45 nm
Processor system typeUp
Processor manufacturerIntel
Processor front side bus800 MHz
Processor operating modes64-bit
ECC supported by processorNo
Thermal Design Power (TDP)35 W
CPU multiplier (bus/core ratio)12
Number of Processing Die Transistors410 M
Motherboard chipsetIntel® PM965 Express
HDD speed5400 RPM
HDD interfaceSATA
Optical drive typeDVD±RW
Card reader integratedYes
Total storage capacity160 GB
Compatible memory cardsSD
Display diagonal14.1 \
Display resolution1280 x 800 pixels
Native aspect ratio16:10
Memory slots2x SO-DIMM
Internal memory2 GB
Memory clock speed667 MHz
Internal memory typeDDR2-SDRAM
Discrete graphics card modelAMD Mobility Radeon X2300
Maximum graphics card memory0.128 GB
Audio systemHD
TypePC
Wireless technology802.11a/b/g/draft-n
Compatible operating systemsFreeDOS Genuine Windows Vista Enterprise Genuine Windows 2000 SuSe Linux Enterprise Desktop 10
Networking typeFast Ethernet
Networking features10/100/1000 NIC
Operating system installedWindows Vista Business
Number of battery cells6
TV-out typeS-Video
Charging port typeDC-in jack
Serial ports quantity0
USB 2.0 ports quantity3
Cable lock slot typeKensington
AC adapter power90 W
Pointing deviceTouchpad + Pointing Stick
Processor codeSLAPR
Processor ARK ID33099
Processor package size35 x 35 mm
Country of originChina
Weight and Dimensions IconWeight and Dimensions
Depth239.5 mm
Width330 mm
Weight2000 g
Height (front)29.1 mm
