HP Compaq 6910p Specifications

Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
*
indicates the profile is also supported by Microsoft Windows XP SP2
Environmental Data
Environmental DataEnvironmental Data
Environmental Data Eco-Label Certifications
Eco-Label CertificationsEco-Label Certifications
Eco-Label Certifications This product has received or is in the process of being certified to the
following approvals and may be labeled with one or more of these marks:
ENERGY STAR 4.0
US Federal Energy Management Program (FEMP)
Taiwan Green Mark
China Energy Conservation Program (CECP)
ECO declaration
Korean Eco Label
EPEAT Silver Rating
System Configuration
System ConfigurationSystem Configuration
System Configuration The configuration used for the Energy Consumption and Declared Noise
Emissions data is based on a “Typically Configured Notebook”
Energy Consumption
Energy ConsumptionEnergy Consumption
Energy Consumption 115 VAC
115 VAC115 VAC
115 VAC 230 VAC
230 VAC230 VAC
230 VAC 100 VAC
100 VAC100 VAC
100 VAC
Normal Operation 13.89 W 13.86 W 13.87 W
Sleep (Energy Star low
power mode)
0.8524 W 1.028 W 0.8504 W
Off 1.258 W 1.48 W 1.225 W
Heat Dissipation*
Heat Dissipation*Heat Dissipation*
Heat Dissipation* 115 VAC
115 VAC115 VAC
115 VAC 230 VAC
230 VAC230 VAC
230 VAC 100 VAC
100 VAC100 VAC
100 VAC
Normal Operation 47.392 BTU/hr 47.29 BTU/hr 47.324 BTU/hr
Sleep 2.908 BTU/hr 3.507 BTU/hr 2.901 BTU/hr
Off 4.292 BTU/hr 5.049 BTU/hr 4.179 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the
service level is attained for one hour.
This product is in compliance with US executive order 13221, WOL (wake
on LAN) disabled.
Declared Noise Emissions
Declared Noise EmissionsDeclared Noise Emissions
Declared Noise Emissions
(in accordance with ISO
7779 and ISO 9296)
Sound Power
Sound PowerSound Power
Sound Power
(LWAd, bels)
Sound Pressure
Sound PressureSound Pressure
Sound Pressure
(LpAm, decibels)
Idle 3.2 25
Operating mode (HDD) 4.7 40
Batteries
BatteriesBatteries
Batteries This product complies with ISO standards:
EU Directive 91/ 157/ EEC
EU Directive 93/ 86/ EEC
EU Directive 98/ 101/ EEC
Batteries used in the product do not contain:
Mercury greater the 5ppm by weight
Cadmium greater than 10ppm by weight
Lead greater than 4000 ppm by weight.
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Technical Specifications
DA - 12699 Worldwide — Version 13 — November 14, 2007 Page 42

HP Compaq 6910p Specifications

General

Bus type	FSB
Stepping	M0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	T8300
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo T8000 Series
Processor socket	Socket 479
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.4 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor system type	Up
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	12
Number of Processing Die Transistors	410 M
Motherboard chipset	Intel® PM965 Express
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD±RW
Card reader integrated	Yes
Total storage capacity	160 GB
Compatible memory cards	SD
Display diagonal	14.1 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Memory slots	2x SO-DIMM
Internal memory	2 GB
Memory clock speed	667 MHz
Internal memory type	DDR2-SDRAM
Discrete graphics card model	AMD Mobility Radeon X2300
Maximum graphics card memory	0.128 GB
Audio system	HD
Type	PC
Wireless technology	802.11a/b/g/draft-n
Compatible operating systems	FreeDOS Genuine Windows Vista Enterprise Genuine Windows 2000 SuSe Linux Enterprise Desktop 10
Networking type	Fast Ethernet
Networking features	10/100/1000 NIC
Operating system installed	Windows Vista Business
Number of battery cells	6
TV-out type	S-Video
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	3
Cable lock slot type	Kensington
AC adapter power	90 W
Pointing device	Touchpad + Pointing Stick
Processor code	SLAPR
Processor ARK ID	33099
Processor package size	35 x 35 mm
Country of origin	China

Weight and Dimensions

Depth	239.5 mm
Width	330 mm
Weight	2000 g
Height (front)	29.1 mm
