HP Compaq 6910p Specifications

Graphics
GraphicsGraphics
Graphics Models with discrete graphics:
ATI Mobility Radeon X2300 graphics with 64 or 128 MB dedicated video memory
(256 MB HyperMemory*)
Models with integrated graphics:
Mobile Intel GMA X3100 graphics with up to 384 MB shared system memory
Microsoft DirectX9 capable
*Indicates dedicated video memory and shared system memory. Either 64MB or 128MB dedicated video
memory, depending on model.
Display
DisplayDisplay
Display Internal
InternalInternal
Internal 14.1-inch diagonal WXGA anti-glare (1280 x 800 resolution)
14.1-inch diagonal WXGA+ anti-glare (1440 x 900 resolution)
Ambient Light Sensor
Optional HP Privacy Filter
External
ExternalExternal
External Up to 32-bit per pixel color depth
VGA
VGAVGA
VGA port supports resolutions up to 2048 x 1536 at 75 Hz, and lower
resolutions at up to 100 Hz
DVI
DVIDVI
DVI port in optional HP Docking Station (sold separately)
supports resolutions up to 1600 x 1200 at both full and reduced
blanking, and 1920 x 1200 at reduced blanking
NOTE:
NOTE: NOTE:
NOTE: Resolutions are dependent upon monitor capability, and resolution
and color depth settings.
Memory
MemoryMemory
Memory Standard
StandardStandard
Standard 512-MB, 1024-MB, 2048-MB, or 4096-MB 667-MHz DDR2 SDRAM; two
SODIMM slots supporting dual channel memory
Maximum
MaximumMaximum
Maximum Upgradeable to 4096-MB with 2048-MB SODIMMs in slots 1 and 2
Dual-channel
Dual-channelDual-channel
Dual-channel Maximized dual-channel performance requires SODIMMs of the same size
and speed in both memory slots.
NOTE:
NOTE: NOTE:
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend
HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the
lower memory speed. Availability of 4 GB of memory requires Windows Vista Business 64-bit or Linux.
With Windows 32-bit operating systems, memory above 3 GB may not all be available due to system
resource requirements.
Communications
CommunicationsCommunications
Communications Integrated Intel Gigabit Network Connection (10/100/1000 NIC)*
56K V.92 modem**
* The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for
Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission,
connection to a Gigabit Ethernet server and network infrastructure is required.
** Designed for downloads from 56K modem compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability
is subject to country regulatory approval.
Wireless Devices
Wireless DevicesWireless Devices
Wireless Devices Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring
support for the latest industry standards. Wireless LAN is factory configurable or available as an option
to be added later. Broadband Wireless (WWAN) requires Windows Vista Business or Windows XP
Professional and is available in select countries as a standard, factory configurable feature or as an
QuickSpecs
HP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PCHP Compaq 6910p Notebook PC
HP Compaq 6910p Notebook PC
Standard Features
DA - 12699 Worldwide — Version 13 — November 14, 2007 Page 5

HP Compaq 6910p Specifications

General

Bus type	FSB
Stepping	M0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	T8300
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo T8000 Series
Processor socket	Socket 479
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.4 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor system type	Up
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	12
Number of Processing Die Transistors	410 M
Motherboard chipset	Intel® PM965 Express
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD±RW
Card reader integrated	Yes
Total storage capacity	160 GB
Compatible memory cards	SD
Display diagonal	14.1 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Memory slots	2x SO-DIMM
Internal memory	2 GB
Memory clock speed	667 MHz
Internal memory type	DDR2-SDRAM
Discrete graphics card model	AMD Mobility Radeon X2300
Maximum graphics card memory	0.128 GB
Audio system	HD
Type	PC
Wireless technology	802.11a/b/g/draft-n
Compatible operating systems	FreeDOS Genuine Windows Vista Enterprise Genuine Windows 2000 SuSe Linux Enterprise Desktop 10
Networking type	Fast Ethernet
Networking features	10/100/1000 NIC
Operating system installed	Windows Vista Business
Number of battery cells	6
TV-out type	S-Video
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	3
Cable lock slot type	Kensington
AC adapter power	90 W
Pointing device	Touchpad + Pointing Stick
Processor code	SLAPR
Processor ARK ID	33099
Processor package size	35 x 35 mm
Country of origin	China

Weight and Dimensions

Depth	239.5 mm
Width	330 mm
Weight	2000 g
Height (front)	29.1 mm
