Security
SecuritySecurity
Security
Trusted Platform Module (TPM) 1.2
1
Stringent Security (via BIOS)
2
SATA Port Disablement (via BIOS)
Drive Lock
RAID Configurations
HP ProtectTools security software
Serial, Parallel, USB enable/disable (via BIOS)
Optional USB Port Disable at factory (user configurable via BIOS)
Removable Media Write/Boot Control
Power-On Password (via BIOS)
Setup Password (via BIOS)
Solenoid Hood Lock / Sensor
Support for chassis padlocks and cable lock devices
1
TPM module disabled where use is restricted by law; for example, Russia.
2
This setting is defaulted to disable, but when enabled, the PW jumper will not clear the BIOS pre-boot authentication
passwords.
Network Interface Connection
Network Interface ConnectionNetwork Interface Connection
Network Interface Connection
Intel 82578 GbE Network Connection (integrated)
Intel Gigabit CT Desktop NIC Card
Broadcom NetXtreme GbE Ethernet Plus NIC (PCIe x1)
NOTE:
NOTE:NOTE:
NOTE:
The integrated network connection is required to support the vPro Technology features.
HP 802.11 b/g/n Wireless NIC (PCIe x1)
NOTE:
NOTE: NOTE:
NOTE:
These wireless network interface solutions will disable the vPro Technology features.
Modem
ModemModem
Modem
LSI Hi-Speed 56K International Soft Modem (PCIe x1)
Graphics
GraphicsGraphics
Graphics
Integrated graphics with Intel Pentium processor, Intel Core i3 processors,
and select Intel Core i5 processors:
Intel HD Graphics (integrated) on selected models
Available discrete graphics cards:
NVIDIA GeForce 310 DP PCIe x16 Graphics Card
Nvidia Quadro NVS 290 Graphics Card
Nvidia Quadro NVS 295 Graphics Card
ATI Radeon HD 4550 Graphics Card
QuickSpecs
HP Compaq 8100 Elite PC
HP Compaq 8100 Elite PCHP Compaq 8100 Elite PC
HP Compaq 8100 Elite PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13524 Worldwide — Version 5 — February 3, 2010
Page 12
