HP Compaq 8100 Elite Quickspecs

3
Technical telephone support applies only to HP configured, HP and HP qualified third party hardware and software. Toll-free
calling and 24 x 7 support may not be available in some countries.
Power Supply
Power SupplyPower Supply
Power Supply
Small Form Factor
Small Form FactorSmall Form Factor
Small Form Factor Convertible Minitower
Convertible MinitowerConvertible Minitower
Convertible Minitower
Standard Efficiency 240W active PFC 320W active PFC
High Efficiency * 240W active PFC
87/89/85% efficient at 20/50/100% load
320W active PFC
87/89/85% efficient at 20/50/100% load
Operating Voltage Range 90 – 264 VAC 90 – 264 VAC
Ports
PortsPorts
Ports
USB 2.0 Front – four (4) ports
Rear – six (6) ports
Serial One port standard; second port available optionally
Parallel One port available optionally
eSATA One port available optionally
PS/2 Color coded support for keyboard (purple) and mouse (green)
Video VGA and DisplayPort provide integrated dual independent monitor support
DVI output Available via optional DisplayPort to DVI Adapter
Audio Front – microphone & headphone
Rear – line input (supports microphone or line input), line out
NOTE:
NOTE: NOTE:
NOTE: See Audio/Visual section for information on re-taskable audio ports. DisplayPort
also supports audio.
NIC Industry standard RJ-45 port accesses the integrated network interface controller
Slots
SlotsSlots
Slots
Type and quantity (1) PCI
(1) PCI Express x1
(2) PCI Express x16
(3) PCI
(1) PCI Express x1 (half-length)
(2) PCI Express x16
Slot specifications Low Profile
25W max. cards
Full height
75W max. for cards in both x16 slots
Primary x16 slot supports 75W or 35W card
Secondary x16 slot supports 35W card when
primary slot is limited to 35W card
Secondary slot functions electrically as an
x4 slot
Chipset
ChipsetChipset
Chipset
Intel Q57 Express supporting Intel® Core™ processor with vPro™ technology
Processors
ProcessorsProcessors
Processors
NOTE:
NOTE: NOTE:
NOTE: all models configured with Intel® Core™ processors with 4 cores require a discrete graphics solution
Intel Pentium Processors:
Intel Pentium Processors:Intel Pentium Processors:
Intel Pentium Processors:
Intel Pentium G6950 Processor
2.80 GHz, 3M total cache
2 cores/2 threads
Integrated Intel® HD Graphics
Intel Core i3 Processors:
Intel Core i3 Processors:Intel Core i3 Processors:
Intel Core i3 Processors:
QuickSpecs
HP Compaq 8100 Elite PC
HP Compaq 8100 Elite PCHP Compaq 8100 Elite PC
HP Compaq 8100 Elite PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13524 Worldwide — Version 5 — February 3, 2010 Page 6

HP Compaq 8100 Elite Specifications

General

Chipset	Intel Q57 Express
Processor	Intel Core i5 or i7
Memory	Up to 16 GB DDR3 SDRAM
Storage	SATA hard drives up to 1 TB
Graphics	Integrated Intel HD Graphics
Optical Drive	DVD-ROM
Operating System	Windows 7 Professional
Form Factor	Small Form Factor (SFF), Convertible Minitower (CMT)
Audio	Integrated High Definition Audio with Realtek ALC261 codec
Network	Integrated Gigabit Ethernet
Ports	USB 2.0, DisplayPort, VGA, serial, parallel, PS/2
Power Supply	240W (SFF), 320W (CMT)
