System memory can be upgraded without removing the system board or any internal components
Tool-less Hard Drive, CD & Diskette Removal
Green Pull Tabs, and Quick Release Latches for easy Identification
Additional Features
Additional FeaturesAdditional Features
Additional Features
Description
DescriptionDescription
Description
Computrace
Computrace agent included; separate software and subscription required
DT or MT Orientation
Product can be oriented in either a tower or desktop orientation
Drive Lock
Implementation of the industry standard ATA Security feature set. When enabled, it
prevents software access to user data on the drive until one or two user-defined
passwords are provided.
Drive Protection System
DPS Access through F10 Setup during Boot
A diagnostic hard drive self test. It scans critical physical components and every
sector of the hard drive for physical faults and then reports any faults to the user.
Running independently of the operating system, it can be accessed through a
Windows-based diagnostics utility or through the computer's setup procedure. It
produces an evaluation on whether the hard drive is the source of the problem
and needs to be replaced.
The system expands on the Self-Monitoring, Analysis, and Reporting Technology
(SMART), a continuously running systems diagnostic that alerts the user to certain types
of failures.
SMART Technology (Self-Monitoring,
Analysis and Reporting Technology)
SMART I – Drive Failure Prediction
SMART II – Off-Line Data Collection
SMART III – Off-Line Read Scanning with
Defect Reallocation
SMART IV – End-to-End CRC for hard
drives
Allows hard drives to monitor their own health and to raise flags if imminent failures
were predicted
Predicts failures before they occur. Tracks fault prediction and failure indication
parameters such as re-allocated sector count, spin retry count, calibration retry
count
By avoiding actual hard drive failures, SMART hard drives act as "insurance"
against unplanned user downtime and potential data loss from hard drive failure
IOEDC: I/O Error Detection Circuitry
Detects errors in Read/Write buffers on HDD cache RAM
Interface in F10 setup provides confirmation of SMART IV support.
QuickSpecs
HP Compaq 8100 Elite PC
HP Compaq 8100 Elite PCHP Compaq 8100 Elite PC
HP Compaq 8100 Elite PC
Technical Specifications
DA - 13524 Worldwide — Version 5 — February 3, 2010
Page 20

Other manuals for HP Compaq 8100 Elite

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Compaq 8100 Elite and is the answer not in the manual?

HP Compaq 8100 Elite Specifications

General IconGeneral
ChipsetIntel Q57 Express
ProcessorIntel Core i5 or i7
MemoryUp to 16 GB DDR3 SDRAM
StorageSATA hard drives up to 1 TB
GraphicsIntegrated Intel HD Graphics
Optical DriveDVD-ROM
Operating SystemWindows 7 Professional
Form FactorSmall Form Factor (SFF), Convertible Minitower (CMT)
AudioIntegrated High Definition Audio with Realtek ALC261 codec
NetworkIntegrated Gigabit Ethernet
PortsUSB 2.0, DisplayPort, VGA, serial, parallel, PS/2
Power Supply240W (SFF), 320W (CMT)
