Redundant Array of Independent Drives (RAID)
Redundant Array of Independent Drives (RAID)Redundant Array of Independent Drives (RAID)
Redundant Array of Independent Drives (RAID)
DriveLock is supported while in RAID mode. Users can manage the DriveLock password from within F10 Setup. Locked drives
will be displayed as such in the RAID option ROM interface.
Hard drive information can be viewed within F10 Setup while in RAID mode. Previously, the hard drives will not appear in
Drive Configuration when switching to RAID mode.
DPS Self Test can be executed on physical hard drives while in RAID mode.
The RAID Setup Utility (accessed through CTRL-I) can be protected by the F10 Setup password.
NOTE:
NOTE:NOTE:
NOTE:
RAID 1 is the only RAID configuration offered via factory configurations. The pre-configured systems:
Are complete RAID systems and have both drives installed. If the CMT is configured with three hard disk drives, the third drive
is would be unpartitioned and not part of the RAID array
Have the necessary Option ROM configuration.
Are pre-loaded and pre-installed with all required Intel software.
Include a preinstalled operating system that is mirrored mode out of the box.
Please refer to the HP White Paper titled "Advanced Host Controller Interface (AHCI) and Redundant Array of Independent Disks
(RAID) on HP Compaq 8100 Elite Series PCs" at:
http://www.hp.com
for more information and instructions.
DDR3 Synchronous DRAM NON-ECC System Memory
DDR3 Synchronous DRAM NON-ECC System MemoryDDR3 Synchronous DRAM NON-ECC System Memory
DDR3 Synchronous DRAM NON-ECC System Memory
Memory upgrades are accomplished by adding single or multiple DIMMs of the same or varied sizes. This chart does not represent all
possible memory configurations. The HP Compaq 8100 Elite Series PC supports non-ECC DDR3 PC3-10600 (1333 MHz)* and
PC3-8500 (1066 MHz)* memory.
CAUTION:
CAUTION: CAUTION:
CAUTION:
You must shut down the computer and disconnect the power cord before adding or removing memory modules.
Regardless of the power-on state, voltage is always supplied to the memory modules as long as the computer is plugged in to an
active AC outlet. Adding or removing memory modules while voltage is present may cause irreparable damage to the memory
modules or system board.
Supports up to 16 GB of DDR3 SDRAM using DIMM modules. Slot 1 is black and must always be populated. Not all memory
configurations possible are represented below.
NOTE:
NOTE: NOTE:
NOTE:
For systems configured with more than 3 GB of memory and a 32-bit operating system, all memory may not be available due
to system resource requirements. Addressing memory above 4 GB requires a 64-bit operating system.
QuickSpecs
HP Compaq 8100 Elite PC
HP Compaq 8100 Elite PCHP Compaq 8100 Elite PC
HP Compaq 8100 Elite PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13524 Worldwide — Version 5 — February 3, 2010
Page 8
