Single-channel and dual-channel memory organization modes
Data burst length of eight for all memory organization modes
DDR3 memory data transfer rates of 1066 MT/s (PC3-8500) and 1333 MT/s (PC3-10600)
64-bit wide channels
DDR3 I/O voltage of 1.5V
Maximum memory bandwidth of 10.6 GB/s in single-channel mode or 21 GB/s in dual-channel mode assuming DDR3 1333 MT/s
(PC3-10600)
The largest memory capacity possible is 32GB using four (4) 8GB DIMMs
CAUTION:
You
must shut down the computer and disconnect the power cord before adding or removing memory modules. Regardless
of the power-on state, voltage is always supplied to the memory modules as long as the computer is plugged in to an active AC outlet.
Adding or removing memory modules while voltage is present may cause irreparable damage to the memory modules or system board.
Memory Configurations:
Ultra Slim Desktop
Slot 1 is black and must always be populated. Not all memory configurations possible are represented below.
NOTE:
For systems configured with more than 3 GB of memory and a 32-bit operating system, all memory may not be available due to system
resource requirements. Addressing memory above 4 GB requires a 64-bit operating system
Total Memory
Socket
Channel A (black)
Channel B (black)
2 GB
(dual channel)
1 GB 1 GB
4 GB
(dual channel)
2 GB 2 GB
8 GB
(dual channel)
4 GB 4 GB
Memory Configurations:
Small Form Factor
Microtower
Convertible Minitower
Slot 1 is black and must always be populated. Not all memory configurations possible are represented below.
NOTE:
For systems configured with more than 3 GB of memory and a 32-bit operating system, all memory may not be available due to system
resource requirements. Addressing memory above 4 GB requires a 64-bit operating system.
QuickSpecs
HP Compaq 8200 Elite Series
Standard Features and Configurable Components (availability may vary by country)
DA - 13879 Worldwide — Version 34 — November 26, 2012
Page 11
