NOTE:
60-R denotes reduced blanking timings are used on single link DVI connections and may be used with other digital connections.
AMD Radeon HD 5450 Graphics Card
Form Factor
MXM 3.0 A
Engine Clock
650 MHz
Memory Type
DDR3
Memory Data Rate
800 MHz
Memory Size (width)
512 MB (64 bit)
3D API support
DX11, SM 5
LVDS support
Yes
Output Connectors
VGA & DisplayPort 1.1 supporting dual independent displays
HDCP support
yes
HDMI support
1.3 compatible
BD support
Full rate playback @ max. resolution of display
Full sub-video support w/o frame drops
Full BDJ or iHD support w/o frame drops
Total Power Consumption
25W
AMD Radeon HD 6350 Graphics Card
Form Factor
PCI Express x16 (generation 2.0)
Low Profile, half length, 2.3" x 6.6"
Full height bracket utilized when configured to CMT or MT
Graphics Controller
AMD HD 6350 GPU
Output Connector
Single DMS-59 connector
Supports dual analog displays with included DMS-59 to dual VGA cable.
Supports dual DVI displays with optional DMS-59 to dual DVI cable.
Core Clock
650MHz
Memory Clock
800MHz
Memory Frame Buffer
512MB, DDR3, 64-bit wide
Supported Graphics APIs
HDCP supported on DVI output using optional DMS-59 to dual DVI cable.
DirectX 11 support in hardware.
OpenGL 4.0 support in hardware.
Display Resolutions and Refresh Rates
NOTE:
other resolutions may be available but are not recommended as they may not have been tested and qualified by HP
Resolution
Maximum Refresh Rate (Hz)
Analog
Digital
640 x 480
85 60
800 x 600
85 60
1024 x 768
85 60
1280 x 720
85 60
QuickSpecs
HP Compaq 8200 Elite Series
Technical Specifications - Graphics
DA - 13879 Worldwide — Version 34 — November 26, 2012
Page 36
