1920 x 1200
85
60-R
1920 x 1440
85 60
*
2048 x 1536
75 60
*
2560 x 1600
N/A
60
*
* Only supported when using a dual link DVI or DisplayPort monitor connection
NOTE:
60-R denotes reduced blanking timings are used on single link DVI connections and may be used with other digital connections.
AMD Radeon HD 6570 Graphics Card
Form Factor
PCI Express x16 (generation 2.0)
Full height for CMT or MT chassis.
Graphics Controller
AMD HD 6570 GPU
Output Connector
Two (2) DisplayPort 1.1
One (1) Dual Link DVI-I
Includes a DVI-I to VGA adapter. Other optional adapter kits are available to support DVI-D, and HDMI
monitor inputs (see complete listing of available optional adapters elsewhere in this QuickSpec).
Supports audio with video through the DisplayPort 1.1 connector. Audio is also supported with an
optional DisplayPort to HDMI Adapter.
DisplayPort 1.2 support will be provided in a future driver update.
Core Clock
650MHz
Memory Clock
900MHz
Memory Frame Buffer
1GB of DDR3,128-bit wide
Supported Graphics APIs
HDCP supported on DisplayPort and DVI output.
DirectX 11 support in hardware.
OpenGL 4.0 support in hardware
Display Resolutions and Refresh Rates
NOTE:
other resolutions may be available but are not recommended as they may not have been tested and qualified by HP
Resolution
Maximum Refresh Rate (Hz)
Analog
Digital
640 x 480
85 60
800 x 600
85 60
1024 x 768
85 60
1280 x 720
85 60
1280 x 1024
85 60
1440 x 900
75 60
1600 x 1200
85 60
1680 x 1050
75 60
1920 x 1080
85
60-R
1920 x 1200
85
60-R
1920 x 1440
85 60
2048 x 1536
75 60
2560 x 1600
N/A
60
NOTE:
60-R denotes reduced blanking timings are used on single link DVI connections and may be used with other digital connections.
QuickSpecs
HP Compaq 8200 Elite Series
Technical Specifications - Graphics
DA - 13879 Worldwide — Version 34 — November 26, 2012
Page 38
