EL-MF877-00 Page 4
Template Revision A
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
FIGURE 1: Removing the access panel.
FIGURE 2: Removing the front bezel
FIGURE 3: Type 1 battery holder
