HP Compaq dc7100 CMT User Manual

2-8 361834-001 Technical Reference Guide
System Overview
Figure 2-5 shows the front panel components of the microtower (uT) form factor.
Figure 2-5. HP Compaq dx6100 MT Front View
Item Description Item Decription
1 CD-ROM drive 7 CD-ROM drive open/close button
2 CD-ROM drive activity LED 8 Power button
3 Diskette drive media door 9 Power LED
4 Diskette drive activity LED 10 Hard drive activity LED
5 Diskette drive eject button 11 Headphone audio Out jack
6 USB ports 7, 8 12 Microphone audio In jack

HP Compaq dc7100 CMT Specifications

General

Memory	Up to 4 GB DDR2 SDRAM
Operating System	Windows XP Professional
Processor	Intel Pentium 4
Chipset	Intel 915G Express
Storage	40GB to 160GB SATA HDD
Graphics	Integrated Intel Graphics Media Accelerator 900
Optical Drive	DVD-ROM, CD-RW, DVD+/-RW
Network	Integrated Gigabit Ethernet
Form Factor	Convertible Minitower
Expansion Slots	1 PCI Express x16, 3 PCI
Ports	USB 2.0, serial, parallel, PS/2, audio in/out
