Serviceability Features of System
Serviceability Features of SystemServiceability Features of System
Serviceability Features of System
Dual Color Power LED on Front of Computer (Indicates Normal Operations and Fault Conditions)
Diagnostic LED Explanation Table
Number of 1-second red LED blinks followed by 2-second pause, then repeats:
2-processor thermal protection activated
3-processor not installed
4-power supply failure
5-memory error
6-video error
7-PCA failure (ROM detected failure prior to video)
8-invalid ROM, bootblock recover mode
System/Emergency ROM
Flash ROM
CMOS Battery Holder for easy
Replacement
Flash Recovery with Video
Configuration Record SW
5 Aux Power LED on System PCA
Processor ZIP Socket for easy Upgrade
Over-Temp Warning on Screen
(Requires IM Agents)
Clear Password Jumper
DIMM Connectors for easy Upgrade
OS CD (Restore OS CD)
Clear CMOS Button
NIC LEDs (integrated) (Green &
Amber)
Restore CD
Serviceability Features of Chassis
Serviceability Features of ChassisServiceability Features of Chassis
Serviceability Features of Chassis
Dual Color Power and HD LED –
To Indicate Normal Operations
and Fault Conditions
Color coordinated cables and
connectors
Tool-less Hood Removal
Front power switch
System memory can be upgraded
without removing the system board or
any internal components
Tool-less Hard Drive, CD & Diskette
Removal
Green Pull Tabs, and Quick
Release Latches for easy
Identification
Tool-less System Board Removal
NOTE:
NOTE:NOTE:
NOTE:
Thumb screw release mechanism is used with the Ultra-slim Desktop chassis cover.
Feature
FeatureFeature
Feature
Description
DescriptionDescription
Description
ASF 2.0 support (Alert Standard Format)
Industry-standard specification for network alerting in operating system-absent environments
Towerable
Product can be oriented as a tower (in addition to desktop orientation)
Drive Self Tests (DPS)
Drive Protection System
A diagnostic hard drive self test. It scans critical physical components and every
sector of the hard drive for physical faults and then reports any faults to the user.
Running independently of the operating system, it can be accessed through a
Windows-based diagnostics utility or through the computer's setup procedure. It
produces an evaluation on whether the hard drive is the source of the problem and
needs to be replaced.
The system expands on the Self-Monitoring, Analysis, and Reporting Technology
(SMART), a continuously running systems diagnostic that alerts the user to certain
types of failures
DPS Access through F10 Setup during
Boot
QuickSpecs
HP Compaq dc7600 Business PC
HP Compaq dc7600 Business PCHP Compaq dc7600 Business PC
HP Compaq dc7600 Business PC
Technical Specifications
DA - 12253 North America — Version 36 — January 30, 2007
Page 24
