HP Compaq dx7500 User Manual

Other Ports Front :
MT: (1) audio out; (1) microphone in, (1) 1394 port
SFF: (1) audio out; (1) microphone in
Rear :
(2) PS/2 ports (keyboard and mouse)
(1) analog VGA video port
(1) DVI port
(1) SPDIF coaxial input
(1) SPDIF coaxial output
(1) audio in, (1) audio out; (1) microphone in
(1) RJ-45 network port
(1) 1394 port
Weight & Dimensions
(MT)
Chassis Dimensions
(H x W x D)
15.14 x 7.27 x 16.36 in
385 x 185 x 416 mm
Packaged Dimensions
(L x W x H)
19.13 x 21.875 x 10.13 in
490 x 556 x 257 mm
System Weight 22.4 lb (10.2 kg)
Shipping Weight 30.8 lb (14.0 kg)
Weight & Dimensions
(SFF)
Chassis Dimensions
(H x W x D)
3.98 x 13.35 x 15.24 in
101 x 339 x 387 mm
Packaged Dimensions
(L x W x H)
23.38 x 19.68 x 9.0 in
593.8 x 500.0 x 228.6 mm
System Weight 14.96 lb (6.79 kg)
Shipping Weight 23.00 lb (10.43 kg)
Technology and Features Memory Type PC2-6400 DDR2 SDRAM (800MHz) non-ECC
Up to 16 GB system memory standard
NOTE: For systems configured with more than 3 GB of memory and a 32-bit operating system, all
memory may not be available due to system resource requirements. Addressing memory above 4 GB
requires a 64-bit operating system.
Hard Drive Interfaces
Supported
Serial ATA
QuickSpecs
HP Compaq dx7500 Business PC
System Details
DA - 13152 Worldwide QuickSpecs — Version 9 — 3/30/2009 Page 9

HP Compaq dx7500 Specifications

General

Brand	HP
Model	Compaq dx7500
Category	Desktop
Language	English
