Removing the Monitor Pedestal Base

You can remove the monitor panel from the pedestal base to install the panel on a wall, a swing arm,

or other mounting fixture.

CAUTION: Before beginning to disassemble the monitor, be sure the monitor is turned off and the

power and signal cables are disconnected. Also disconnect all USB cables connected to the monitor.

1. Disconnect and remove the signal, power, and USB cables from the monitor.

2. Lay the monitor face down on a flat surface covered by a clean, dry cloth.

3. Pivot the base 45 degrees clockwise and remove the screw from the back of the monitor, then

pivot the base 45 degrees counter-clockwise and remove the other screw from the back of the

monitor.

Figure 3-11 Removing the Pedestal Base Screws

4. Rotate the base of the monitor up (1) then pull it back (2) to unhinge the tabs on the monitor

stand from the slots in the monitor.

Figure 3-12 Removing the Pedestal Base

ENWW Removing the Monitor Pedestal Base 13
