Table 4-2 OSD Menu (continued)
Icon Main Menu Submenu Description
Factory Reset Returns all OSD menu settings and DDC/CI controls
to the factory default settings, except the Language.
Source Control Selects the video input signal. DP (DisplayPort) is
the factory default.
DisplayPort Selects DisplayPort as the video input signal.
DVI Selects DVI as the video input signal.
VGA Selects VGA as the video input signal.
Default Source Selects the default or primary video input signal
when the monitor is connected to two active and
valid video sources. The monitor will automatically
determine the video format. The choices are:
DisplayPort
DVI
VGA
The factory default is DisplayPort.
Auto-Switch Source Turns the system's automatic video signal input to
On or Off. The factory default is On.
Source Detection This option is displayed in the OSD when a
DisplayPort input is selected. You can set Source
Detection to:
Always Active
Low Power
The factory default is Low Power.
Exit Exits the OSD menu screen.
24 Chapter 4 Operating the Monitor ENWW

Table of Contents

Other manuals for HP Compaq LA2206xc

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Compaq LA2206xc and is the answer not in the manual?

HP Compaq LA2206xc Specifications

General IconGeneral
Screen Size21.5 inches
Resolution1920 x 1080
Panel TypeTN
Aspect Ratio16:9
Brightness250 cd/m²
Contrast Ratio1000:1
Response Time5 ms
Built-in WebcamNo
Dynamic Contrast Ratio1, 000, 000:1
Viewing Angle (Horizontal)170°
Viewing Angle (Vertical)160°
HDCP SupportYes
Built-in SpeakersNo
Height AdjustmentYes
PivotYes
SwivelYes
ConnectivityVGA, DVI
