Component Description
(1) Webcam light On: The webcam is in use.
(2) Webcam Records video and captures still photographs.
NOTE: To capture and edit videos, you can use the
preinstalled Arcsoft WebCam Companion 3 software
(3) Internal microphone Records sound.
(4) Speakers (2) Produce sound.
(5) Volume mute action key (f11) Mutes or restores speaker sound.
(6) Volume up action key (f10) Increases speaker volume.
(7) Volume down action key (f9) Decreases speaker volume.
(8) Audio-out (headphone) jack/Audio-in
(microphone) jack
Produces sound when connected to optional powered stereo
speakers, headphones, earbuds, a headset, or television
audio. Also connects an optional headset microphone.
WARNING! To reduce the risk of personal injury, adjust the
volume before putting on headphones, earbuds, or a headset.
For additional safety information, refer to the Regulatory,
Safety and Environmental Notices.
40 Chapter 5 Multimedia
