5–6 Maintenance and Service Guide
Removal and Replacement Procedures
4. Remove the battery pack by following these steps:
a. Turn the computer upside down with the front toward you.
b. Slide the battery release latch 1 toward the back of the
computer. (The right side of the battery pack disengages
from the computer.)
c. Lift the right side of the battery pack and swing it to the
left 2 and remove it.
Removing the Battery Pack
Reverse the above procedure to install the battery pack.
Battery Pack Spare Part Number Information
6-cell battery pack 419111-001
