HP Compaq nx6310 User Manual

Display
DisplayDisplay
Display Internal
InternalInternal
Internal 15.0-inch XGA (1024 x 768 resolution)
15.0-inch XGA BrightView (1024 x 768 resolution)
15.0-inch SXGA+ wide viewing angle (1400 x 1050 resolution)
External
ExternalExternal
External Up to 32-bit per pixel color depth
VGA
VGAVGA
VGA port supports resolutions up to 2048 x 1536 at 75 Hz, and lower
resolutions at up to 100 Hz
NOTE:
NOTE:NOTE:
NOTE: Resolutions are dependent upon monitor capability, and resolution
and color depth settings.
Memory
MemoryMemory
Memory Standard
StandardStandard
Standard 256-MB, 512-MB, 1024-MB or 2048-MB 533-MHz or 667-MHz* DDR2
SDRAM; two SODIMM slots supporting dual channel memory
Maximum
MaximumMaximum
Maximum Intel 945GM Express Chipset supports up to 4096-MB maximum (2048-MB
533- or 667-MHz SODIMM in slots 1 and 2)
Intel 940GML Express Chipset supports up to 2048-MB maximum (1024-MB
533- or 667-MHz SODIMM in slots 1 and 2)
Dual-channel
Dual-channelDual-channel
Dual-channel Maximized dual-channel performance requires SODIMMs of the same size
and speed in both memory slots.
* 667-MHz memory is supported at a maximum speed of 533 MHz by the Mobile Intel 940GML Express
Chipset.
NOTE:
NOTE: NOTE:
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend
HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the
lower memory speed. Above 3-GB, all memory may not be available due to system resource
requirements.
Communications
CommunicationsCommunications
Communications Integrated Broadcom 10/100 Ethernet PCI Controller
56K V.92 modem* with digital line guard
* Designed for downloads from 56K modem compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability
is subject to country regulatory approval.
Wireless Devices
Wireless DevicesWireless Devices
Wireless Devices Support for a broad range of secure, integrated wireless LAN options featuring support for the latest
industry standards. Integrated Bluetooth is also an option (factory configurable only) and can be
combined with any of the supported wireless LAN options.
All integrated wireless
All integrated wirelessAll integrated wireless
All integrated wireless
LAN options
LAN optionsLAN options
LAN options
Wi-Fi certified
Cisco Compatible Extensions support (Version 3.0)
Wired Equivalent Privacy (WEP) support up to 128-bit keys
Wi-Fi Protected Access (WPA) and WPA2 support
802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, and LEAP
Advanced Encryption Standard (AES) support
WiFi certified for WPA2, WMM
Dual antennas integrated in the display enclosure
Intel PRO/Wireless
Intel PRO/WirelessIntel PRO/Wireless
Intel PRO/Wireless
3945ABG Network
3945ABG Network3945ABG Network
3945ABG Network
Connection
ConnectionConnection
Connection
Intel Centrino mobile technology
Integrated support for 802.11a, b and g
Up to 54-mbps data rate
Broadcom 4311AG WiFi
Broadcom 4311AG WiFiBroadcom 4311AG WiFi
Broadcom 4311AG WiFi
Adapter
AdapterAdapter
Adapter
Integrated support for 802.11a, b and g
Up to 54-mbps data rate
QuickSpecs
HP Compaq nx6310 Notebook PC
HP Compaq nx6310 Notebook PCHP Compaq nx6310 Notebook PC
HP Compaq nx6310 Notebook PC
Standard Features
DA - 12432 North America — Version 20 — August 2, 2007 Page 4

HP Compaq nx6310 Specifications

General

Display diagonal	15 \
Display resolution	1024 x 768 pixels
Native aspect ratio	4:3
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD±RW
Total storage capacity	60 GB
Bluetooth	No
Networking features	Ethernet/Fast Ethernet
AC adapter power	65 W
Audio system	Intel High Definition Audio
Cache external	1 KB
Processor cache	1 MB
Processor family	Intel® Celeron® M
Processor frequency	1.46 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor front side bus	533 MHz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Non-operating relative humidity (non-condensing)	5 - 95 %
Bundled software	Microsoft Windows Media Player 10
Operating system installed	Windows XP Home Edition
Discrete graphics card	Yes
Discrete graphics card model	Intel® GMA 950
Maximum graphics card memory	0.128 GB
Motherboard chipset	Intel® 945GM Express
Memory slots	2x SO-DIMM
Internal memory	0.5 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	2 GB
Modem speed	56 Kbit/s
Dimensions (WxDxH)	329 x 267 x 30 mm
Wireless technology	IEEE 802.11b/g
Keyboard layout	QWERTY
Pointing device	Touchpad
Cable lock slot type	Kensington
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	2
CardBus PCMCIA slot type	Type II
Country of origin	China

Weight and Dimensions

Depth	267 mm
Width	329 mm
Height	30 mm
Weight	2700 g
