HP Compaq NX9420 Quickspecs

1.
2.
3.
4.
5.
Power Management ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
4
54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm
Antenna type High efficiency dual band antenna with spatial diversity, mounted in the
display enclosure
Range 802.11 b – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor PCI-Express MiniCard
Weight 0.026 lb (12 g)
Dimensions 0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
Operating Voltage 3.3v +/- 10%
Temperature Operating
Non-operating
32° to 176° F (0° to 80° C)
-40° to 176° F (-40° to 80° C)
Humidity Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
Configuration Utility
5
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Broadcom Wireless Configuration Utility (required for Cisco Compatible
Extensions support)
LED Activity LED Off – Radio OFF; Solid LED On – Radio ON
Check latest software/driver release for updates on supported security features.
Maximum output power may vary by country according to local regulations.
In Power Save Polling mode.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a
packet error rate of 10% for 802.11a/g (OFDM modulation).
WLAN supplier's client utility is required for Cisco Compatible Extensions support. WLAN may also be
compatible with certain third-party software supplicants.
Intel PRO/Wireless
3945ABG 802.11a/b/g
Network Connection
Wireless LAN Standards IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
Interoperability Wi-Fi certified
Cisco Compatible Extensions Program compliant
(details at www.hp.com/go/notebooks/WLAN )
Frequency Band 2.4 GHz and 5 GHz
Data Rates 802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Modulation Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES,
QuickSpecs
HP Compaq nx9420 Notebook PC
Technical Specifications
DA - 12427 North America — Version 22 — October 5, 2007 Page 35

HP Compaq NX9420 Specifications

General

HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Total storage capacity	100 GB
Display diagonal	17 \
AC adapter power	90 W
Audio system	HP Premier Sound high-definition Audio 24-bits audio DAC, Digital EQ
Number of built-in speakers	2
Bus type	FSB
Stepping	C0
Tjunction	100 °C
Cache external	2048 KB
Processor cache	2 MB
Processor model	T2400
System bus rate	- GT/s
Processor family	Intel® Core™ Duo
Processor series	Intel Core Duo T2000 Series
Processor socket	Socket 478
Processor codename	Yonah
Processing Die size	90 mm²
Processor frequency	1.83 GHz
Processor cache type	L2
Processor technology	Intel Centrino Duo Mobile
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	667 MHz
Processor operating modes	32-bit
ECC supported by processor	No
Thermal Design Power (TDP)	31 W
CPU multiplier (bus/core ratio)	11
Number of Processing Die Transistors	151 M
Storage temperature (T-T)	-40 - 80 °C
Operating temperature (T-T)	0 - 80 °C
Operating relative humidity (H-H)	10 - 90 %
Non-operating relative humidity (non-condensing)	5 - 95 %
Memory slots	2x SO-DIMM
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Internal modem	Yes
Expansion slots	1 Type I/II PC Card slot supports 32-bit CardBus, 16-bit cards, 7 in 1 media reader: Secure Digital, MultiMediaCard, Memory Stick, Stick Pro or Stick Duo, Smart Media and xD memory cards
Dimensions (WxDxH)	33 x 393 x 275 mm
Wireless technology	Intel Wireless LAN 802.11a/b/g, MOW2, Bluetooth
Diskette drive memory	No MB
Video card features	ATI Mobility Radeon X1600
Bundled software	Microsoft Windows Media Player 10, Microsoft Direct X9 Adobe Acrobat Reader, HP software voor sneltoetsen, HP Wireless Assistant, HP ProtectTools, HP Backup- en recoveryoplossing, HP Mobile printerdriver, HP OpenView Radia Management Agent, InterVideo WinDVD
Operating system installed	Windows XP Professional
Motherboard chipset	Intel® 945PM Express
Battery life (max)	4 h
Number of battery cells	8
Networking features	Broadcom Gigabit (10/100/1000 NIC) PCI Express Ethernet controller
Cable lock slot type	Kensington
Discrete graphics card model	AMD Mobility Radeon X1600
Maximum graphics card memory	0.256 GB
TV-out type	S-Video
Charging port type	DC-in jack
USB 2.0 ports quantity	4
Parallel ports quantity	0
CardBus PCMCIA slot type	Type II
Firewire (IEEE 1394) ports	1
Processor ARK ID	27235
Processor package size	35 x 35 mm
Country of origin	China

Weight and Dimensions

Depth	393 mm
Width	33 mm
Height	275 mm
Weight	3350 g
