HP Compaq NX9420 Quickspecs

1.
2.
3.
4.
5.
Configuration Utility
5
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Intel PROSet (required for Cisco Compatible Extensions support)
LED Activity LED Off – Radio OFF; Solid LED On – Radio ON
Check latest software/driver release for updates on supported security features.
Maximum output power may vary by country according to local regulations.
In Power Save Polling mode.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a
packet error rate of 10% for 802.11a/g (OFDM modulation).
WLAN supplier's client utility is required for Cisco Compatible Extensions support. WLAN may also be
compatible with certain third-party software supplicants.
HP Integrated Module
with Bluetooth Wireless
Technology
Bluetooth Specification 2.0 Compliant
Dimensions 1.02 x 0.55 x 0.22 in (26 x 14 x 5.7 mm)
Frequency Band 2402 to 2480 MHz
Number of Available
Channels
79 (1 MHz) available channels
Data Rates and
Throughput
3 Mbps data rate; throughput up to 2.17 Mbps
Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric or
1306.9 kbps symmetric
Transmit Power -6 dBm to 4 dBm (Bluetooth Class II)
Receiver Sensitivity Better than -80 dBM at 0.1 % raw bit error rate
Power Consumption Peak (Tx) 264 mW
Peak (Rx) 231 mW
Sleep <1 mW
Antenna Internally integrated within module
Range Up 33 ft (10 m)
Electrical Interface USB 2.0 compliant
Microsoft Windows Plug and Play compliant
OS Support Microsoft Windows XP Professional and Home
Microsoft Windows 2000
Bluetooth Software
Supported
Broadcom Bluetooth for Windows
Microsoft Windows XP Bluetooth Software
Link Topology Point to Point, Multipoint Pico Nets up to 7 slaves
Security Full support of Bluetooth Security Provisions
Power Management Microsoft Windows ACPI, and USB Bus Support
Self configurable to optimize power conservation in all operating modes,
including Standby, Hold, Park, and Sniff
Certifications All necessary regulatory approvals for supported countries, including:
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
QuickSpecs
HP Compaq nx9420 Notebook PC
Technical Specifications
DA - 12427 North America — Version 22 — October 5, 2007 Page 37

HP Compaq NX9420 Specifications

General

HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Total storage capacity	100 GB
Display diagonal	17 \
AC adapter power	90 W
Audio system	HP Premier Sound high-definition Audio 24-bits audio DAC, Digital EQ
Number of built-in speakers	2
Bus type	FSB
Stepping	C0
Tjunction	100 °C
Cache external	2048 KB
Processor cache	2 MB
Processor model	T2400
System bus rate	- GT/s
Processor family	Intel® Core™ Duo
Processor series	Intel Core Duo T2000 Series
Processor socket	Socket 478
Processor codename	Yonah
Processing Die size	90 mm²
Processor frequency	1.83 GHz
Processor cache type	L2
Processor technology	Intel Centrino Duo Mobile
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	667 MHz
Processor operating modes	32-bit
ECC supported by processor	No
Thermal Design Power (TDP)	31 W
CPU multiplier (bus/core ratio)	11
Number of Processing Die Transistors	151 M
Storage temperature (T-T)	-40 - 80 °C
Operating temperature (T-T)	0 - 80 °C
Operating relative humidity (H-H)	10 - 90 %
Non-operating relative humidity (non-condensing)	5 - 95 %
Memory slots	2x SO-DIMM
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Internal modem	Yes
Expansion slots	1 Type I/II PC Card slot supports 32-bit CardBus, 16-bit cards, 7 in 1 media reader: Secure Digital, MultiMediaCard, Memory Stick, Stick Pro or Stick Duo, Smart Media and xD memory cards
Dimensions (WxDxH)	33 x 393 x 275 mm
Wireless technology	Intel Wireless LAN 802.11a/b/g, MOW2, Bluetooth
Diskette drive memory	No MB
Video card features	ATI Mobility Radeon X1600
Bundled software	Microsoft Windows Media Player 10, Microsoft Direct X9 Adobe Acrobat Reader, HP software voor sneltoetsen, HP Wireless Assistant, HP ProtectTools, HP Backup- en recoveryoplossing, HP Mobile printerdriver, HP OpenView Radia Management Agent, InterVideo WinDVD
Operating system installed	Windows XP Professional
Motherboard chipset	Intel® 945PM Express
Battery life (max)	4 h
Number of battery cells	8
Networking features	Broadcom Gigabit (10/100/1000 NIC) PCI Express Ethernet controller
Cable lock slot type	Kensington
Discrete graphics card model	AMD Mobility Radeon X1600
Maximum graphics card memory	0.256 GB
TV-out type	S-Video
Charging port type	DC-in jack
USB 2.0 ports quantity	4
Parallel ports quantity	0
CardBus PCMCIA slot type	Type II
Firewire (IEEE 1394) ports	1
Processor ARK ID	27235
Processor package size	35 x 35 mm
Country of origin	China

Weight and Dimensions

Depth	393 mm
Width	33 mm
Height	275 mm
Weight	3350 g
