HP Compaq NX9420 Quickspecs

Audio ADI High Definition CODEC
Integrated 16-bit Sound Blaster Pro compatible audio
Integrated stereo speakers
Integrated directional microphone
External volume up, volume down, and mute buttons
Stereo headphone/line out
Stereo microphone in
Software Software Adobe Acrobat Reader
HP Backup and Recovery Manager
HP Help and Support
HP Mobile Print Driver
HP ProtectTools Security Manager:
BIOS Configuration for HP ProtectTools
Embedded Security for HP ProtectTools
Credential Manager for HP ProtectTools
HP Quick Launch Buttons
HP Wireless Assistant
Sonic Digital Media Plus:
RecordNow! (for optional DVD+/-RW and DVD/CDRW drives)
MyDVD (DVD Authoring for optional DVD+/-RW drives)
Synaptics Touchpad Driver
Symantec Norton Internet Security with complimentary 60-day live update
Intervideo WinDVD – DVD Player (for optional DVD+/-RW, DVD/CDRW and DVD
drives)
Additional software
available from the Web
Smart Card Security for HP ProtectTools
Device Access Manager for HP ProtectTools
HP Backup and Recovery
Manager
Each unit is shipped with HP Backup and Recovery Manager. HP Backup and Recovery Manager can provide
data and system file protection for HP business PCs to enable fast recovery if the system becomes
corrupted or if important information is accidentally deleted. HP Backup and Recovery Manager can
perform scheduled or manual backups of the entire drive or individual files and folders. Up to 8 GB is
reserved for the system recovery software. HP Backup and Recovery Manager can also create software
recovery CDs or DVDs (requires optional hardware).
SMBIOS Version 2.4 System Management BIOS, previously known as DMI BIOS, is used to store system management
information.
QuickSpecs
HP Compaq nx9420 Notebook PC
Standard Features
DA - 12427 North America — Version 22 — October 5, 2007 Page 7

HP Compaq NX9420 Specifications

General

HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Total storage capacity	100 GB
Display diagonal	17 \
AC adapter power	90 W
Audio system	HP Premier Sound high-definition Audio 24-bits audio DAC, Digital EQ
Number of built-in speakers	2
Bus type	FSB
Stepping	C0
Tjunction	100 °C
Cache external	2048 KB
Processor cache	2 MB
Processor model	T2400
System bus rate	- GT/s
Processor family	Intel® Core™ Duo
Processor series	Intel Core Duo T2000 Series
Processor socket	Socket 478
Processor codename	Yonah
Processing Die size	90 mm²
Processor frequency	1.83 GHz
Processor cache type	L2
Processor technology	Intel Centrino Duo Mobile
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	667 MHz
Processor operating modes	32-bit
ECC supported by processor	No
Thermal Design Power (TDP)	31 W
CPU multiplier (bus/core ratio)	11
Number of Processing Die Transistors	151 M
Storage temperature (T-T)	-40 - 80 °C
Operating temperature (T-T)	0 - 80 °C
Operating relative humidity (H-H)	10 - 90 %
Non-operating relative humidity (non-condensing)	5 - 95 %
Memory slots	2x SO-DIMM
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Internal modem	Yes
Expansion slots	1 Type I/II PC Card slot supports 32-bit CardBus, 16-bit cards, 7 in 1 media reader: Secure Digital, MultiMediaCard, Memory Stick, Stick Pro or Stick Duo, Smart Media and xD memory cards
Dimensions (WxDxH)	33 x 393 x 275 mm
Wireless technology	Intel Wireless LAN 802.11a/b/g, MOW2, Bluetooth
Diskette drive memory	No MB
Video card features	ATI Mobility Radeon X1600
Bundled software	Microsoft Windows Media Player 10, Microsoft Direct X9 Adobe Acrobat Reader, HP software voor sneltoetsen, HP Wireless Assistant, HP ProtectTools, HP Backup- en recoveryoplossing, HP Mobile printerdriver, HP OpenView Radia Management Agent, InterVideo WinDVD
Operating system installed	Windows XP Professional
Motherboard chipset	Intel® 945PM Express
Battery life (max)	4 h
Number of battery cells	8
Networking features	Broadcom Gigabit (10/100/1000 NIC) PCI Express Ethernet controller
Cable lock slot type	Kensington
Discrete graphics card model	AMD Mobility Radeon X1600
Maximum graphics card memory	0.256 GB
TV-out type	S-Video
Charging port type	DC-in jack
USB 2.0 ports quantity	4
Parallel ports quantity	0
CardBus PCMCIA slot type	Type II
Firewire (IEEE 1394) ports	1
Processor ARK ID	27235
Processor package size	35 x 35 mm
Country of origin	China

Weight and Dimensions

Depth	393 mm
Width	33 mm
Height	275 mm
Weight	3350 g
