Removal and Replacement Procedures
Maintenance and Service Guide 5–17
5.8 RTC Battery
1. Prepare the computer for disassembly (Section 5.3).
2. Remove the memory/Mini Card module compartment cover
(Section 5.6).
3. Remove the Mini Card communications module
(Section 5.7).
4. Remove the RTC battery from the socket on the
system board.
Removing the RTC Battery
Reverse the above procedure to install an RTC battery.
RTC Battery Spare Part Number Information
RTC battery (includes tape) 407816-001
